Description

Technical Specifications

• Film Thickness (without liner): 0.12 mm

• Total Thickness (with liner): 0.28 mm

• Film Type: Medium-grade polymeric calendared vinyl with air-release channels

• Adhesive: Transparent Henkel solvent-based acrylic; ultra-weather-resistant

  • Viscosity: 1000–3000 cps

  • Dry adhesive thickness: 12 μm

• Release Liner:

  • Felix Schoeller Kraft paper (ISO 9001, ISO 14001, OHSAS 18001 certified)

  • Double-sided PE-coated, one side solventless silicone, air-release treated

Storage & Durability

• Storage Life: 3 years (stored at +10°C to +20°C, 50% RH, in original packaging, away from sunlight)

• Warranty & Lifespan: See full datasheet for coverage and durability expectations

• Dimensional Stability: Shrinkage < 0.20%

• Plasticizer Content: 25% – 32%

• Breaking Strength: 30.7 N/10mm (ASTM D3759)

• 180º Peel Strength (to steel): 9 N/10mm (ASTM D3330)

UV Aging Test Results

• Test Methods: ASTM D4329-13 Cycle A / ISO 105-A02:1993

• Lamp Type: UVA-340

• Test Conditions:

  • 8 hours UV at 60°C ±2.5°C

  • 4 hours condensation at 50°C ±2.5°C

• Result: Grade 4–5 (excellent resistance)

• Total Exposure Duration: 48 hours

Installation Guidelines

• Application Temperature: +18°C to +20°C

• Service Temperature Range: -30°C to +30°C

• Tools Required: Standard squeegee with soft buffer

• Conformability: Ideal for smooth and medium-curved surfaces

• Material Directionality: Yes (align patterns consistently)

• Recommended Overlap Width: 3–4 mm

• Protective Layer: Peel off before heat application

Packaging

• Roll Width: 152 cm

• Roll Length: 15 m

Important Notes

• Colors and textures may vary slightly on screens. Always verify with a physical swatch for accurate representation.

• Use rolls from the same production LOT to ensure color consistency across full wrap projects.

• The film surface may be prone to light scratches during installation or regular use. These are not covered under warranty.
