Description

Technical Specifications

• Film Thickness (without liner): 0.12 mm

• Total Thickness (with liner): 0.28 mm

• Type: Medium-grade polymeric calendared vinyl with air-release

• Series: 180 Series

Adhesive

• Type: Transparent Henkel solvent-based acrylic adhesive

• Viscosity: 1000–3000 cps

• Thickness (dry): 12 μm

• Ultra weather-resistant

Release Liner

• Brand: Felix Schoeller 20-104-20-1.9

• Dual PE-coated Kraft, one side silicone-coated

• Features air-release channels

• Certifications: ISO 9001, ISO 14001, OHSAS 18001

Storage & Durability

• Shelf Life: 3 years when stored at +10°C to +20°C, 50% humidity, in original packaging

• Dimensional Stability: Shrinkage < 0.20%

• Plasticizer Content: 25%–32%

• Breaking Strength: 30.7 N/10mm (ASTM D3759)

• 180º Peel Strength (to steel): 9 N/10mm (ASTM D3330)

• Warranty: See [Datasheet] for details

UV Resistance (Light Aging)

• Test Standard: ASTM D4329-13 Cycle A / ISO 105-A02:1993

• Lamp Type: UVA-340

• Conditions:

  • 8h UV at (60 ± 2.5)°C

  • 4h condensation at (50 ± 2.5)°C

  • Total Exposure: 48 hours

• Result: 4–5 (Excellent)

Installation Guide

• Recommended Application Temp: +18°C to +20°C

• Usage Temp Range: -30°C to +30°C

• Tools Required: Soft buffer squeegee

• Surface Compatibility: Smooth to medium curved

• Film Directionality: Yes – ensure uniform direction during application

• Overlap Margin: 3–4 mm

⚠️ Important: Remove the protective PET cap before installation to avoid adhesion issues.

Packaging Details

• Roll Width: 152 cm

• Roll Length: 15 m

Please Note

• Product images shown on-screen may slightly vary from the actual color. Always confirm final selection using a physical color swatch.

• Use rolls from the same production LOT to avoid minor color discrepancies during large-scale wrap projects.

• While highly durable, this vinyl may develop minor scratches during installation or daily use. These are not covered by warranty.
