Description
Technical Specifications
Film Thickness: 110 μm
Release Liner Thickness: 142 μm
Film Type: High-grade polymeric calendered vinyl with air-release channels
Adhesive: Henkel solvent-based acrylic; ultra-weather-resistant; viscosity: 1000–3000 cps; dry thickness: 12 μm
Release Liner: Plastic liner for enhanced gloss
Storage & Durability
Shelf Life: 2 years (stored at +10°C to +20°C, 50% RH, in original packaging, away from sunlight)
Important: Remove the PET protective cap before installation. Do not store film with the cap to avoid tunneling.
Warranty: See datasheet for full details
Performance Testing
| Test Item | Standard | Result (23°C, 54% RH) |
|---|---|---|
| Release Force (N/25mm) | 0.10 – 0.30 | 0.18 |
| Initial Tack (g/25mm, GB31125-2014) | 800 – 1500 | 1015 |
| 180° Peel Strength (GB/T2792-1998) | ≥ 4.9 | 8.1 |
| Adhesion Strength (GB/T4851-1998) | ≥ 60 | 70 (No shifting) |
Aging Tests
High Temperature (65°C, 7 days): No adhesive residue
Low Temperature (-65°C, 10 days): No adhesive residue
Installation Guidelines
Application Temperature: +16°C to +18°C
Operating Temperature Range: -30°C to +45°C
Tools Required: Standard squeegee with soft buffer
Conformability: Smooth and medium-curved surfaces
Directionality: Non-directional
Overlap Width: 3–4 mm
Post-Heating Temperature: 95°C
⚠️ Always remove the PET protective cap before heat application during installation.
Packaging
Roll Width: 152 cm
Available Lengths: 15 m
Important Notes
On-screen images and colors are approximate. For accurate results, always verify using a physical swatch.
Use rolls from the same LOT number to maintain color consistency across panels.
The film surface may scratch during installation or regular use. Such wear is not covered under warranty.
