Description

Technical Specifications
Film Thickness: 110 μm

Release Liner Thickness: 142 μm

Film Type: High-grade polymeric calendered film with integrated air-release channels

Adhesive: Henkel solvent-based acrylic (ultra-weather-resistant); viscosity: 1000–3000 cps; dry thickness: 12 μm

Release Liner: Gloss-enhancing plastic liner

Storage & Durability
Shelf Life: Up to 2 years (store at +10°C to +20°C, 50% RH, in original packaging, away from sunlight)

Note: Always remove the protective PET layer before installation and avoid storing the film with it to prevent tunneling.

Warranty: Refer to official datasheet for details.

Performance Test Results
Test Type Standard Range Result (23°C, 54% RH)
Release Force (N/25mm) 0.10 – 0.30 0.18
Initial Tack (g/25mm, GB31125-2014) 800 – 1500 1015
180° Peel Strength (N/25mm, GB/T2792-1998) ≥ 4.9 8.1
Adhesion Strength (GB/T4851-1998) ≥ 60 70 (No shifting)

Aging Tests
High Temp (65°C, 7 days): No adhesive residue

Low Temp (-65°C, 10 days): No adhesive residue

Installation Guidelines
Application Temperature: +16°C to +18°C

Operating Temperature Range: -30°C to +45°C

Tools Recommended: Standard squeegee with soft felt buffer

Conformability: Suitable for flat to moderately curved surfaces

Directional: No

Overlap Width: 3–4 mm

Post-Heating Temperature: 95°C

⚠️ Always peel off the PET protective cap before installation.

Packaging
Roll Width: 152 cm

Roll Length Options: 15 m

Important Notes
Colors, textures, and finishes displayed on screen are approximate. For an accurate match, always check a physical color swatch.

Use rolls from the same production LOT for color consistency across a full wrap.

The film may be prone to scratches during installation or regular use, which is not covered under warranty.
