Description

Technical Specifications

• Film Thickness: 121 μm

• Liner Thickness: 180 μm

• Material: High-grade polymeric calendared vinyl with air-release channels

• Application: Suitable for full wraps or partial applications on smooth or moderately curved surfaces

Adhesive & Liner

• Adhesive: Henkel solvent-based acrylic

  • Transparent, ultra-weather-resistant

  • Viscosity: 1000–3000 cps

  • Dry Thickness: 12 μm

• Release Liner: Felix Schoeller double PE-coated Kraft paper

  • Solventless silicone coating

  • Certifications: ISO 9001, ISO 14001, OHSAS 18001

Performance Data

• Storage Life: 3 years (store at +10°C to +20°C, 50% RH, away from sunlight)

• Peel Strength (180°): 11.17 N/25mm (Test: GB/T2792-1998)

• Initial Tack: 1254 g/25mm (Test: GB31125-2014)

• Adhesion Strength: 70 (Test: GB/T4851-1998) – No shifting

• Release Force: 0.1 N/25mm (Standard: 0.04–0.12)

• Dimensional Stability: High, with no adhesive residue during aging tests

  • Heat aging: 65°C for 7 days – No residue

  • Cold aging: -65°C for 10 days – No residue

Installation Guidelines

• Application Temp: +17°C to +18°C

• Service Range: -45°C to +45°C

• Post-Heating: 100°C

• Tools: Soft squeegee with buffer

• Conformability: Flat and moderately curved surfaces; deep recesses require inlays

• Material Directionality: Yes

• Overlap Margin: 4–5 mm

Packaging

• Roll Width: 152 cm

• Roll Length: 15 m

Important Notes

• Product images and colors on screen are approximate; always refer to a physical color swatch for accuracy.

• To avoid visible shade variation, use rolls from the same LOT number for a single project.

• Due to the nature of the material, surface scratching may occur during installation or daily use—this is not covered under warranty.
