Description

Technical Specifications

• Film Thickness (without liner): 0.12 mm

• Total Thickness (with liner): 0.28 mm

• Film Type: Medium-grade polymeric calendared vinyl with air-release channels

• Series: 180 Series

• Adhesive: Transparent Henkel solvent-based acrylic adhesive

  • Viscosity: 1000–3000 cps

  • Dry adhesive thickness: 12 μm

• Release Liner: Felix Schoeller 20-104-20-1.9

  • Double PE-coated Kraft, one side solventless silicone-coated

  • Certified: ISO 9001, ISO 14001, OHSAS 18001

Storage & Durability

• Shelf Life: 3 years (stored at +10°C to +20°C, 50% RH, in original packaging, out of direct sunlight)

• Dimensional Stability: Shrinkage < 0.20%

• Plasticizer Content: 25% – 32%

• Breaking Strength: 30.7 N/10mm (ASTM D3759)

• 180º Peel Strength (to steel): 9 N/10mm (ASTM D3330)

• Warranty: See full datasheet for durability and coverage

UV Aging Resistance

• Test Standards: ASTM D4329-13 Cycle A, ISO 105-A02:1993

• Lamp Type: UVA-340

• Test Conditions:

  • 8h UV at 60°C ±2.5°C

  • 4h condensation at 50°C ±2.5°C

  • Total exposure: 48 hours

• Result: Grade 4–5 (excellent resistance)

Installation Guidelines

• Application Temperature: +18°C to +20°C

• Operating Temperature Range: -30°C to +30°C

• Required Tools: Standard squeegee with a soft buffer

• Conformability: Ideal for smooth and medium curved surfaces

• Material Directionality: Yes (align for consistent finish)

• Recommended Overlap Width: 3–4 mm

• Protective Cap: Must be removed before installation

Packaging

• Roll Width: 152 cm

• Roll Length: 15 m

Important Notes

• Colors and finishes shown on screen are approximate. For true accuracy, refer to a physical color swatch.

• Use rolls from the same LOT number to ensure color consistency across your full project.

• This film may be susceptible to surface scratches during installation or regular use. Scratches are not covered under warranty.
