Description

Product Specifications

• Film Thickness: 0.12 mm

• Total Thickness (with liner): 0.28 mm

• Film Type: Medium-grade polymeric calendared vinyl with air-release channels

• Series: 180 Series

Adhesive & Release Liner

• Adhesive: Henkel solvent-based acrylic

  • Transparent, ultra-weather-resistant

  • Viscosity: 1000–3000 cps

  • Thickness (dry): 12 μm

• Release Liner: Felix Schoeller double PE-coated Kraft

  • Solventless silicone-coated

  • ISO 9001 / ISO 14001 / OHSAS 18001 certified

Performance Data

• Storage Life: 3 years (store at +10°C to +20°C, 50% RH, in original packaging, away from sunlight)

• Dimensional Stability: Shrinkage < 0.20%

• Plasticizer Content: 25%–32%

• Breaking Strength: 30.7 N/10 mm (ASTM D3759)

• Peel Strength to Steel Panel: 9 N/10 mm (ASTM D3330)

UV & Aging Resistance

• Test Method: ASTM D4329-13 Cycle A / ISO 105-A02

• Results: Light aging grade 4–5

• Cycle: 8h UV at 60 ± 2.5°C + 4h condensation at 50 ± 2.5°C

• Lamp Type: UVA-340

• Exposure Duration: 48h

Installation Guidelines

• Recommended Temperature: +18°C to +20°C

• Usage Range: -30°C to +30°C

• Tools: Standard squeegee with soft buffer

• Conformability: Smooth and moderately curved surfaces

• Directional Material: Yes

• Overlap Margin: 3–4 mm

• ⚠️ Remove protective cap before installation.

Packaging Information

• Roll Width: 152 cm

• Roll Length: 15 m

Important Notice

Color and finish may vary slightly depending on screen display. For accurate selection, always consult a physical color swatch.
To ensure color consistency, use rolls from the same production LOT for a single job.
Please note: Minor surface scratching may occur during installation or daily use—this is not covered under warranty.
