Description

Technical Specifications

• Film Thickness (without liner): 0.12 mm

• Total Thickness (with liner): 0.28 mm

• Film Type: Medium-grade polymeric calendared vinyl with air-release channels

• Series: 180 Series

Adhesive & Release Liner

• Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant

• Adhesive Thickness (dry): 12 μm

• Viscosity: 1000–3000 cps

• Release Liner: Felix Schoeller 20-104-20-1.9, double-side PE coated Kraft paper

• Certifications: ISO 9001, ISO 14001, OHSAS 18001

Performance Characteristics

• Storage Life: 3 years (store at +10°C to +20°C, RH 50%, away from sunlight)

• Dimensional Stability: ≤ 0.20% shrinkage

• Plasticizer Content: 25%–32%

• Breaking Strength: 30.7 N/10 mm (ASTM D3759)

• 180° Peel Strength (to steel): 9 N/10 mm (ASTM D3330)

UV Resistance Test

• Method: ASTM D4329-13 Cycle A, ISO 105-A02

• Result: Color fastness rating 4–5

• Exposure Cycle: UVA-340 at 60°C / 4h condensation at 50°C for 48h

Installation Guidelines

• Application Temperature: +18°C to +20°C

• Operating Temperature Range: -30°C to +30°C

• Recommended Tools: Standard squeegee with a soft buffer

• Conformability: Smooth and medium curved surfaces

• Directional Film: Yes

• Overlap Width: 3–4 mm

• ⚠️ Remove the protective cap before installation.

Packaging Details

• Roll Width: 152 cm

• Roll Length: 15 m

Important Notes

• Screen images are for reference only. For accurate color matching, always consult a physical color swatch.

• To ensure consistency, use rolls from the same production LOT number for a single wrap project.

• Minor surface scratches may occur during application or regular use; these are not covered under warranty.
