Technical Specifications

• Film Thickness (without liner): 0.12 mm

• Total Thickness (with liner): 0.28 mm

• Film Type: Medium-grade polymeric calendared vinyl

• Air-Release Technology: Yes

• Series: 180 Series

Adhesive Information

• Type: Henkel solvent-based acrylic adhesive

• Appearance: Transparent

• Viscosity: 1000–3000 cps

• Dry Thickness: 12 μm

• Features: Ultra-weather-resistant, high clarity

Release Liner

• Material: Felix Schoeller PE-coated Kraft paper

• Model: 20-104-20-1.9 (printed)

• Coating: One side solventless silicone, air-release

• Certifications: ISO 9001, ISO 14001, OHSAS 18001

Storage & Shelf Life

• Storage Conditions:

  • Temperature: +10°C to +20°C

  • Relative Humidity: 50%

  • Environment: Clean, dry, away from sunlight

• Shelf Life: Up to 3 years (in original packaging)

Performance Metrics

• Dimensional Stability: ≤ 0.20% shrinkage

• Plasticizer Content: 25%–32%

• Breaking Strength: 30.7 N/10 mm (avg.) — ASTM D3759

• Peel Strength (to steel, 180º): 9 N/10 mm (avg.) — ASTM D3330

UV Resistance Testing

• Standard: ASTM D4329-13 Cycle A / ISO 105-A02

• Lamp: UVA-340

• Conditions:

  • 8h UV exposure at 60±2.5°C

  • 4h condensation at 50±2.5°C

  • Power: 0.89 W/(m²·nm) @ 340nm

  • Duration: 48 hours

• Result: Lightfastness grade 4–5

Installation Guidelines

• Application Temperature: +18°C to +20°C

• Service Temperature: -30°C to +30°C

• Tools: Soft buffer squeegee

• Surface Compatibility: Smooth and medium-curved surfaces

• Film Directionality: Yes

• Recommended Overlap: 3–4 mm

⚠️ Important: Always remove the protective cap before installation.

Packaging

• Roll Width: 152 cm

• Roll Length: 15 m

Important Notes

• Visuals shown on screen may differ slightly from the actual product. Always refer to a physical color swatch for precise color verification.

• For consistent color throughout the application, use rolls from the same production LOT number.

• This film may scratch during installation or daily use. Scratching is not covered under warranty.
