Description

Technical Specifications
Film Thickness: 110 μm

Release Liner Thickness: 142 μm

Film Type: Premium polymeric calendered vinyl with air-release channels

Adhesive: Henkel solvent-based acrylic; ultra-weather-resistant; viscosity: 1000–3000 cps; dry adhesive thickness: 12 μm

Release Liner: Gloss-enhancing plastic liner

Storage & Durability
Shelf Life: 2 years (stored at +10°C to +20°C, 50% RH, in original packaging, away from sunlight)

Important: Always remove the PET protective layer before installation. Storing the film with this layer may cause tunneling.

Warranty: Please refer to the official datasheet for detailed coverage.

Performance Testing
Test Type Standard Result (23°C, 54% RH)
Release Force (N/25mm) 0.10 – 0.30 0.18
Initial Tack (g/25mm, GB31125-2014) 800 – 1500 1015
180° Peel Strength (GB/T2792-1998) ≥ 4.9 8.1
Adhesion Strength (GB/T4851-1998) ≥ 60 70 (No shifting)

Aging Test Results
High Temperature (65°C for 7 days): No adhesive residue

Low Temperature (-65°C for 10 days): No adhesive residue

Installation Guidelines
Application Temperature: +16°C to +18°C

Operating Temperature Range: -30°C to +45°C

Tools Recommended: Standard squeegee with soft buffer

Conformability: Smooth to moderately curved surfaces

Directionality: Non-directional

Overlap Width: 3–4 mm

Post-Heating Temperature: 95°C

⚠️ Be sure to remove the PET protective cap before applying heat during installation.

Packaging
Roll Width: 152 cm

Available Lengths: 15 m

Important Notes
Product images and finishes displayed on screen are for reference only. Always check a physical swatch for precise color matching.

Use rolls from the same production LOT number to ensure color consistency across a full wrap.

The film may scratch during installation or everyday use. Scratches are not covered under the warranty.
