Description

Technical Specifications

• Film Thickness (without liner): 0.12 mm

• Total Thickness (with liner): 0.28 mm

• Film Type: Medium-grade polymeric calendared vinyl with air-release channels

• Adhesive: Transparent Henkel solvent-based acrylic

  • Viscosity: 1000–3000 cps

  • Dry adhesive thickness: 12 μm

• Release Liner: Felix Schoeller 20-104-20-1.9

  • Double PE-coated Kraft

  • One side solventless silicone-coated with air-release

  • Certifications: ISO 9001, ISO 14001, OHSAS 18001

Storage & Durability

• Storage Life: 3 years (stored at +10°C to +20°C, 50% RH, in original packaging, out of direct sunlight)

• Dimensional Stability: Shrinkage < 0.20%

• Plasticizer Content: 25% – 32%

• Breaking Strength: 30.7 N/10mm (ASTM D3759)

• 180° Peel Strength (to steel): 9 N/10mm (ASTM D3330)

• Warranty: See full datasheet for coverage

UV Aging Performance

• Test Standards: ASTM D4329-13 Cycle A, ISO 105-A02:1993

• Lamp Type: UVA-340

• Test Conditions:

  • 8 hours UV at 60°C ±2.5°C

  • 4 hours condensation at 50°C ±2.5°C

  • Total exposure: 48 hours

• Result: Grade 4–5 (excellent aging resistance)

Installation Guidelines

• Application Temperature: +18°C to +20°C

• Usage Temperature Range: -30°C to +30°C

• Tools Needed: Standard squeegee with soft buffer

• Conformability: Suitable for smooth and moderately curved surfaces

• Directional Material: Yes (maintain consistent orientation)

• Overlap Width: 3–4 mm

• Protective Cap: Must be peeled off before installation

Packaging

• Roll Width: 152 cm

• Roll Length: 15 m

Important Notes

• Colors and finishes displayed on-screen are approximate. For precise results, always refer to a physical swatch.

• Use rolls from the same production LOT number to ensure consistent color matching throughout the project.

• The film may be prone to light surface scratches during installation or regular use, which are not covered under warranty.
