Description

Technical Specifications

• Film Thickness (without liner): 0.12 mm

• Total Thickness (with liner): 0.28 mm

• Film Type: Medium-grade polymeric calendared vinyl with air-release channels

• Series: Super Matte 180 Series

Adhesive & Liner

• Adhesive Type: Henkel solvent-based acrylic (transparent)

• Dry Adhesive Thickness: 12 μm

• Viscosity: 1000–3000 cps

• Weather Resistance: Ultra-high

• Release Liner: Felix Schoeller 20-104-20-1.9, double-sided PE-coated Kraft paper

• Certifications: ISO 9001, ISO 14001, OHSAS 18001

Performance & Durability

• Storage Life: 3 years (store at +10°C to +20°C, 50% RH, away from sunlight)

• Dimensional Stability: ≤ 0.20% shrinkage

• Plasticizer Content: 25%–32%

• Breaking Strength: 30.7 N/10 mm (ASTM D3759)

• 180° Peel Strength (to steel): 9 N/10 mm (ASTM D3330)

UV Light Aging Test

• Test Methods: ASTM D4329-13 Cycle A, ISO 105-A02

• Conditions: UVA-340, 60°C exposure, 4h condensation at 50°C

• Result: Color fastness grade 4–5

Installation Guidelines

• Application Temperature: +18°C to +20°C

• Service Temperature Range: -30°C to +30°C

• Tools Required: Standard squeegee with soft buffer

• Conformability: Smooth and moderately curved surfaces

• Directional: Yes

• Overlap Width: 3–4 mm

• 🔧 Always remove the protective cap before installation.

Packaging Details

• Roll Width: 152 cm

• Roll Length: 15 m

Important Notes

• Product visuals on screen are for reference only. For true color accuracy, please refer to the physical swatch book.

• Use rolls from the same LOT number for a consistent finish.

• This film may be prone to surface scratching during application or regular use. Scratches are not covered under warranty.
