Description

Technical Specifications
Film Thickness: 110 μm

Release Liner Thickness: 142 μm

Film Type: High-grade polymeric calendered vinyl with air-release technology

Adhesive: Henkel solvent-based acrylic; ultra-weather-resistant; viscosity: 1000–3000 cps; dry thickness: 12 μm

Release Liner: Gloss-enhancing plastic liner

Storage & Durability
Storage Life: 2 years (store between +10°C and +20°C, 50% RH, in original packaging, out of sunlight)

Important: Always remove the PET protective cap before installation. Avoid storing the film with the cap on to prevent tunneling.

Warranty: See datasheet for full details.

Performance Testing
Test Parameter Standard Result (23°C, 54% RH)
Release Force (N/25mm) 0.10 – 0.30 0.18
Initial Tack (g/25mm, GB31125-2014) 800 – 1500 1015
180° Peel Strength (GB/T2792-1998) ≥ 4.9 8.1
Adhesion Strength (GB/T4851-1998) ≥ 60 70 (No shifting)

Aging Tests
High Temperature (65°C, 7 days): No adhesive residue

Low Temperature (-65°C, 10 days): No adhesive residue

Installation Guidelines
Application Temperature: +16°C to +18°C

Usage Temperature Range: -30°C to +45°C

Recommended Tools: Standard squeegee with a soft buffer

Conformability: Suitable for smooth and medium-curved surfaces

Directionality: Non-directional

Overlap Width: 3–4 mm

Post-Heating Temperature: 95°C

⚠️ Always remove the PET protective cap before applying heat.

Packaging
Roll Width: 152 cm

Roll Length Options: 15 m

Important Notes
Screen-displayed colors, textures, and finishes are approximate. Refer to a physical swatch for true color accuracy.

Always use film from the same production LOT when completing a full wrap to avoid minor color variations.

The film surface may be prone to light scratching during installation or daily use—this is not covered under warranty.
