Description

Technical Specifications
Film Thickness: 110 μm

Release Liner Thickness: 142 μm

Film Type: High-grade polymeric calendered film with air-release channels

Adhesive: Henkel solvent-based acrylic; ultra-weather-resistant; viscosity: 1000–3000 cps; dry thickness: 12 μm

Release Liner: Gloss-enhancing plastic liner

Storage & Durability
Shelf Life: 2 years (store at +10°C to +20°C, 50% RH, in original packaging, away from sunlight)

Important: Always remove the PET protective layer before installation. Do not store the film with the protective cap, as it may cause tunneling.

Warranty: Refer to product datasheet for full details.

Performance Testing
Test Item Standard Result (23°C, 54% RH)
Release Force (N/25mm) 0.10 – 0.30 0.18
Initial Tack (g/25mm, GB31125-2014) 800 – 1500 1015
180° Peel Strength (GB/T2792-1998) ≥ 4.9 8.1
Adhesion Strength (GB/T4851-1998) ≥ 60 70 (no shifting)

Aging Test Results
High Temperature (65°C, 7 days): No adhesive residue

Low Temperature (-65°C, 10 days): No adhesive residue

Installation Guidelines
Recommended Application Temperature: +16°C to +18°C

Usage Temperature Range: -30°C to +45°C

Required Tools: Standard squeegee with soft buffer

Conformability: Suitable for smooth and moderately curved surfaces

Directionality: Non-directional

Overlap Width: 3–4 mm

Post-Heating Temperature: 95°C

⚠️ Be sure to remove the PET protective cap before applying heat during installation.

Packaging Details
Roll Width: 152 cm

Available Lengths: 15 m

Important Notes
Images and finishes displayed on screens are approximate. Always verify color accuracy using a physical color swatch.

Use rolls from the same production LOT number to avoid slight color variation across panels.

While the film offers excellent durability, it may be prone to minor scratches during installation or daily use, which are not covered by warranty.
