Description

Technical Specifications

• Film Thickness (without liner): 0.12 mm

• Film Thickness (with liner): 0.28 mm

• Film Type: Medium-grade polymeric calendared vinyl with air-release channels

Adhesive & Liner

• Adhesive: Henkel solvent-based acrylic, transparent, ultra-weather-resistant

• Dry Adhesive Thickness: 12 μm

• Viscosity: 1000–3000 cps

• Release Liner: Felix Schoeller double PE-coated Kraft (20-104-20-1.9), solventless silicone-coated

• Certifications: ISO 9001, ISO 14001, OHSAS 18001

Performance Data

• Storage Life: 3 years (stored at +10°C to +20°C, RH 50%, away from sunlight)

• Dimensional Stability: ≤ 0.20% shrinkage

• Plasticizer Content: 25%–32%

• Breaking Strength: 30.7 N/10 mm (ASTM D3759)

• Peel Strength to Steel Panel: 9 N/10 mm (ASTM D3330)

UV Resistance Test

• Test Method: ASTM D4329-13 Cycle A / ISO 105-A02

• Lamp Type: UVA-340

• Cycle: 8h UV at 60±2.5°C, 4h condensation at 50±2.5°C

• Duration: 48h exposure

• Result: Grade 4–5 light aging resistance

Installation Tips

• Ideal Application Temperature: +18°C to +20°C

• Usage Temperature Range: -30°C to +30°C

• Recommended Tools: Soft-buffer squeegee

• Conformability: Smooth and moderately curved surfaces

• Directional Film: Yes

• Overlap Width: 3–4 mm

• ⚠️ Remove the protective cap before installation.

Packaging Details

• Roll Size: 152 cm  × 15 m

Important Note

Colors and finishes displayed on digital screens may vary. For precise matching, always check the physical swatch before use.
Use rolls from the same LOT number to ensure consistent color throughout your project.
Note: This film may scratch during application or routine use. Scratches are considered normal wear and are not covered under warranty.
