Description
đ Specifications
| Feature | Details |
|---|---|
| Material Type | High-grade polymeric calendared PVC vinyl with air-release technology |
| Finish | Gloss color-shift, resembling a soft sunset metallic shimmer |
| Series | 190 Series |
| Film Thickness | 0.15 mm |
| Total Thickness (with liner) | 0.31 mm |
| Liner | Felix Schoeller dual PE-coated Kraft with air-release (ISO certified) |
| Adhesive | Henkel solvent-based acrylic adhesive, transparent, ultra-weather-resistant |
| Durability | Datasheet available (Click link) |
| Storage Conditions | 2 years in +10°C to +20°C, 50% RH, no direct sunlight, original packaging |
| Application Temp | +17°C to +18°C |
| Operating Temp Range | -45°C to +45°C |
| Dimensional Stability | <3% (matte), <5% (glossy) |
| Plastification | 27% â 35% |
| Breaking Strength | 22.7 N/10mm (ASTM D3759) |
| Adhesion Strength | 7.4 N/10mm (ASTM D3330) |
| UV Aging Test | Passed, Rating 5 (ASTM D4329 / ISO 105-A02) |
| Post Heating | 110°C recommended for maximum adhesion |
đ ď¸ Installation Tips
Tools Required: Soft squeegee, buffer, masking tape, heat gun, gloves
Surface Compatibility: Smooth to medium-curved surfaces
Directionality: Yes (check wrap orientation before application)
Overlap Width: 3â4 mm
Cure Time: 24 hours above 10°C
đŚ Packaging
Roll Dimensions: 152 cm Ă 15 m
â ď¸ Important Notes
The visual appearance of color, gloss, and finish may vary slightly on-screen. Always confirm with a physical swatch.
For consistent results, use material from the same LOT number throughout the application.
Surface scratches may occur during installation or everyday use. Scratches are not covered under warranty.
Avoid overstretching during application. Always use post-heating to secure edges and recessed areas.
