Description

Technical Specifications

• Film Thickness (without liner): 0.12 mm

• Total Thickness (with liner): 0.28 mm

• Film Type: Medium-grade polymeric calendared vinyl with air-release channels

• Series: 180 Series

Adhesive System

• Type: Henkel solvent-based acrylic adhesive

• Color: Transparent

• Viscosity: 1000–3000 cps

• Dry Thickness: 12 μm

• Features: Ultra weather-resistant, residue-free removal

Release Liner

• Brand: Felix Schoeller 20-104-20-1.9

• Structure: Double-sided PE-coated Kraft paper

• Coating: One side solventless silicone-coated

• Certifications: ISO 9001, ISO 14001, OHSAS 18001

• Technology: Air-release channels for easy, bubble-free application

Performance & Durability

• Storage Life: 3 years (stored at +10°C to +20°C, 50% RH, original packaging)

• Dimensional Stability: Shrinkage < 0.20%

• Plasticizer Content: 25%–32%

• Breaking Strength: 30.7 N/10 mm (ASTM D3759)

• Peel Strength (180° to steel): 9 N/10 mm (ASTM D3330)

• Warranty: Refer to official [Datasheet]

UV Resistance (Accelerated Aging Test)

• Standard: ASTM D4329-13 Cycle A / ISO 105-A02

• Lamp: UVA-340

• Conditions:

  • 8h UV at 60 ± 2.5°C

  • 4h condensation at 50 ± 2.5°C

  • Exposure Duration: 48 hours

• Result: Grade 4–5 (excellent color retention)

Installation Guidelines

• Application Temperature: +18°C to +20°C

• Service Temperature Range: -30°C to +30°C

• Tools: Standard squeegee with soft buffer

• Surface Compatibility: Smooth and medium-curved surfaces

• Directionality: Yes (apply consistently in one direction)

• Overlap Margin: 3–4 mm

⚠️ Important: Remove the PET protective cap prior to installation.

Packaging Details

• Roll Width: 152 cm

• Roll Length: 15 m

Additional Notes

• On-screen colors and finishes are for reference only. Please verify with a physical color swatch for true accuracy.

• Use rolls from the same LOT number to ensure uniform color across panels.

• As with all vinyl wraps, minor scratches may occur during installation or daily use. These are not covered under warranty.
