Description

Technical Specifications
Film Thickness: 110 μm

Release Liner Thickness: 142 μm

Film Type: Premium polymeric calendered vinyl with air-release channels

Adhesive: Henkel solvent-based acrylic adhesive; ultra-weather-resistant; viscosity: 1000–3000 cps; dry thickness: 12 μm

Release Liner: High-gloss plastic liner

Storage & Durability
Shelf Life: 2 years (when stored at +10°C to +20°C, 50% RH, in original packaging, away from sunlight)

Note: Always remove the PET protective cap before installation. Do not store film with the cap to avoid “tunneling.”

Warranty: See full product datasheet for coverage details.

Performance Testing
Test Type Standard Result (23°C, 54% RH)
Release Force (N/25mm) 0.10 – 0.30 0.18
Initial Tack (g/25mm, GB31125-2014) 800 – 1500 1015
180° Peel Strength (GB/T2792-1998) ≥ 4.9 8.1
Adhesion Strength (GB/T4851-1998) ≥ 60 70 (No shifting)

Aging Test Results
High Temperature (65°C for 7 days): No adhesive residue

Low Temperature (-65°C for 10 days): No adhesive residue

Installation Guidelines
Application Temperature: +16°C to +18°C

Usage Temperature Range: -30°C to +45°C

Tools Required: Standard squeegee with a soft buffer

Conformability: Smooth to moderately curved surfaces

Directionality: Non-directional

Overlap Width: 3–4 mm

Post-Heating Temperature: 95°C

⚠️ Be sure to peel off the PET protective cap before starting installation.

Packaging
Roll Width: 152 cm

Roll Length: 15 m

Important Notes
Product images, colors, and finishes shown on screen are approximate. Please consult a physical swatch for accurate reference.

Always use rolls from the same production LOT to avoid minor color variations.

The film may scratch during installation or regular use—scratches are not covered by the warranty.
